Electromagnetic Sieve Shaker
Precision Particle Size Analysis System
Athena Instruments introduces the Electromagnetic Sieve Shaker, a compact, robust, and microprocessor-controlled sieving system designed for accurate and reproducible particle size separation. Engineered for use in laboratories and on-site environments, this system efficiently handles a wide range of particle profiles—including irregular, needle-shaped, and uneven materials—across applications in pharmaceuticals, construction materials, food, mining, and research laboratories.
Operating on the electromagnetic principle, this sieve shaker delivers consistent circular and vertical vibrations, ensuring complete material movement across the sieve surface while minimizing aperture blinding. It supports both continuous and intermittent sieving modes, making it ideal for precise granulometric testing and QA/QC procedures.
Key Features :
- Electromagnetic Vibration: Powered by a non-mechanical, electromagnetic drive system ensuring smooth, quiet operation with minimal maintenance.
- Microprocessor Control: Advanced digital control system with adjustable power (1–20 levels) and timer (1–99 minutes) for repeatable testing conditions.
- Dual Vibration Modes: Choose between continuous operation or intermittent mode (0.5 sec delay) for enhanced sieving of complex particle shapes.
- Wide Compatibility: Supports sieve diameters from 100 mm to 200/203 mm, allowing flexibility across multiple test standards and materials.
- Intuitive LCD Display: 20x4 screen showing real-time power and time settings for user-friendly operation.
- Compact & Efficient Design: Easy-lock system allows fast loading/unloading of sieves with excellent space optimization.
Applications
Pharmaceutical Granulometry
Ensures uniform particle sizing of powders and granules for formulations and tableting.
Construction Material Testing
Ideal for cement, sand, soil, and aggregates analysis in civil and geotechnical labs.
Food
Industry
Used in flour, spice, and grain classification for consistency and quality control.
Mining and Minerals
Reliable for grading ore, rock dust, and extracted mineral particles.
Environmental Testing
Efficiently sieves soil, sediments, and suspended solids for environmental and agricultural studies.
Product Models & Specifications
| Specification | Details |
|---|---|
| Model | ATES-201 |
| Number of Sieves | 8 |
| Dry Sieving | Standard |
| Display | 7 in Touch Screen, High Resolution, Resistive Type |
| Mode of Operation | Continuous, Intermittent, and Logic |
| Intermittent Operation | At interval up to 0.5 seconds |
| Capacity | Up to 8 Sieves of 200 mm Dia x 50 mm height; Up to 16 Sieves of 100 mm Dia x 25 mm height |
| Shake Time | Programmable from 1 min to 99 min |
| Power Level | Programmable from 1 to 20 |
| Amplitude | 0.2 to 3 mm |
| Max. Batch / Feed Capacity | 3 Kg |
| Max. Mass of Sieve Stack | 4 Kg |
| Measuring Range | 20 µm – 25 mm |
| Interval Operation | Combined programming feature of both Continuous and Intermittent |
| Sieving Motion | Digital Amplitude Programming with Throwing Motion and Angular Momentum |
| Noise Level | Less than 60 dB without sieves at maximum amplitude |
|
Suitable Sieves |
100 mm 203 mm |
| Height of Sieve Stack | Up to 785 mm |
| Data Storage | 50 datas |
| User Management | 4-level password (1 Admin, 9 Users) |
| Printer | Dot Matrix Printer 80 C (Ext), USB Interface |
| Dimensions | – |
| Weight |
35 Kg Approx. without sieves |
| Electrical Supply | 115V ± 15V, 50/60 Hz or 230V ± 23V, 50/60 Hz |
Standard Accessories
- Supporting rods (2 Nos.)
- Easy lock knobs (2 Nos.)
- Receiver pan
- Top lid
- Silicone pad
- Power cord
- Operating manual
Additional Technical Highlights
Vibration Type
Electromagnetic oscillation (circular + vertical motion)
Noise Level
Extremely low due to non-mechanical operation
Safety
Overcurrent protection; fuse-based electrical safety built-in
Documentation
IQ/OQ validation documentation included for GMP compliance
Ease of Use
Tool-less setup, quick-release sieve loading, and minimal maintenance required
Materials
Durable MS and aluminum construction with corrosion-resistant finish
Why Choose Athena’s Electromagnetic Sieve Shaker?
Trusted Performance, Certified Quality
Athena’s Electromagnetic Sieve Shaker combines efficiency, safety, and precision with international certification standards. Built for real-world conditions and backed by expert support, it is the go-to solution for high-performance particle size analysis across industries.
