Laboratory Paddle Blender
Sterile Laboratory Sample Homogenizer
High-Efficiency, Contact-Free Blending for Microbiological Applications
Athena Instruments introduces the Laboratory Paddle Blender, a robust and precision-engineered paddle-type homogenizer specifically designed for the sterile, uniform, and gentle blending of solid and semi-solid samples. Crafted with mirror-finish SS304 stainless steel and equipped with advanced microprocessor controls, our blenders ensure exceptional hygiene, durability, and repeatability across industries including food safety, pharmaceuticals, cosmetics, forensics, clinical diagnostics, veterinary medicine, and environmental testing.
Available in multiple sizes with programmable controls, these blenders are rigorously tested for safety, reliability, and ease of use—and are certified to meet global compliance standards, including CE, ISO 9001:2015, FDA, BIS, and EI certifications.
Key Features :
- Advanced Microprocessor Control: Multi-stage programmable settings with precise speed, time, and paddle spacing adjustment for optimal homogenization.
- Built-In UV Sterilization: Integrated UV lamp disinfects the chamber between cycles, ensuring sterile conditions and maintaining sample integrity.
- Touchscreen Display: 4.3” intuitive LCD touchscreen interface for easy parameter setup, real-time monitoring, and operation.
- Customizable Paddle Motion: Adjustable paddle speed (3–12 strokes/sec) and spacing (0–55 mm) to accommodate diverse sample types and textures.
- Heavy-Duty Stainless Steel Construction: Fabricated with mirror-finish SS304 for excellent corrosion resistance and long-term durability.
- Safety Door with Anti-Pinch System: Transparent, heat-dissipating door with auto-stop interlock for operator safety and contact-free blending.
- Disposable Sterile Bags: Single-use homogenizer bags eliminate internal cleaning, reducing cross-contamination risk and simplifying workflows.
- Soft Start & Pause Modes: Smooth ramp-up reduces sample stress and ensures consistent, gentle blending.
Applications
Food
Microbiology
Preparation of meat, dairy, produce, and ready-to-eat food samples for microbial testing.
Pharmaceutical & Cosmetic Testing
Homogenization of raw materials and finished products for quality control in GMP environments.
Forensic & Toxin Analysis
Preparation of complex biological and environmental samples for trace toxin, drug residue, or contaminant analysis.
Clinical & Veterinary Diagnostics
Safe, sterile processing of biological fluids, swabs, and tissue samples.
Environmental Monitoring
Preparation of soil, water, and surface samples for pathogen detection and pollutant assessment.
Product Models & Specifications
|
Model Name |
Volume Capacity |
Paddle Speed |
Paddle Spacing |
Display |
Bag Size (mm) |
Machine Weight |
Dimensions (mm) |
|---|---|---|---|---|---|---|---|
|
ATSB-400 |
100 to 400ml |
180–720 RPM |
0–55 mm |
4.3” LCD Touch |
170 × 300 |
20 kg |
420 × 230 × 330 |
|
ATSB-1000 |
500 to 1000ml |
360–1440 RPM |
0–55 mm |
4.3” LCD Touch |
300 × 500 |
36 kg |
420 × 430 × 440 |
|
ATSB-3750 |
600 to 3000 ml |
360–1440 RPM |
0–55 mm |
4.3” LCD Touch |
355 × 500 |
42 kg |
425 × 450 × 440 |
Note: Includes a starter kit of 50 sterile homogenizer bags for immediate lab deployment. Additional bags available on request.
Additional Technical Highlights
Timer Range:
1 second to 99 hours 59 minutes 59 seconds with multi-stage programmable settings.
Control System:
Advanced memory supports 3-segment programmable combinations for repeatable workflows.
Soft Start Mode:
Gentle acceleration to reduce sample stress and extend machine life.
UV Disinfection Lamp:
Built-in sterilization after each cycle enhances lab biosafety.
Anti-Pinch Safety System:
Auto-stop feature protects users during door operation.
Removable Heat-Dissipating Door:
Easy access for bag loading and cleaning with safety interlocks.
Power Supply:
220 V / 50 Hz – 220 W operation suitable for global lab environments.
Why Choose Athena Instruments Laboratory Paddle Blender?
Trusted Performance, Certified Quality
Athena’s ATSB Series Laboratory Paddle Blenders are manufactured under rigorous in-house quality control protocols and conform to internationally recognized standards. They deliver dependable, contamination-free homogenization for laboratories that demand sterility, precision, and repeatability, ensuring your lab meets the highest standards of safety and quality.
