Ultrasonic Sonicator with Chiller
Precision Sonication with Active Temperature Control
Athena Instruments introduces the Ultrasonic Sonicator with Chiller, an advanced laboratory solution that integrates high-efficiency ultrasonic cleaning with active temperature regulation. Engineered for precision, safety, and reliability, this dual-function system is ideal for laboratories and industries handling heat-sensitive materials, ensuring effective cleaning, degassing, and sonochemical processes.
Built with durable SS304 construction and equipped with imported PZT transducers and digital controls, this system supports applications ranging from analytical sample prep to semiconductor and biotech cleaning processes. With models ranging from 10L to 50L, this product line is suitable for both table top and floor-mounted configurations.
Product Models & Specifications
| Model | Capacity | Tank Size (L×W×H) | Ultrasonic Power | Frequency | Temp. Range | Dimensions (inches) | Power Input |
|---|---|---|---|---|---|---|---|
| ATSC-10-TT | 10 L | 12″ × 9″ × 6″ | 250 W | 33 kHz | 5°C–25°C | 18″ × 16″ × 20″ | 220V–230V |
| ATSC-20-TT | 20 L | 18″ × 12″ × 6″ | 400 W | 33 kHz | 5°C–25°C | 24″ × 20″ × 20″ | 220V–230V |
| ATSC-20-FM | 20 L | 18″ × 12″ × 6″ | 400 W | 33 kHz |
5°C–25°C |
26″ × 20″ × 36″ | 220V–230V |
| ATSC-25-FM | 25 L | 16″ × 16″ × 6″ | 500 W | 33 kHz | 5°C–25°C | 24″ × 24″ × 36″ | 220V–230V |
| ATSC-30-FM | 30 L | 15″ × 15″ × 8″ | 500 W | 33 kHz | 5°C–25°C | 23″ × 23″ × 36″ | 220V–230V |
| ATSC-40-FM | 40 L | 20″ × 20″ × 6″ | 650 W | 33 kHz | 5°C–25°C | 24″ × 24″ × 36″ | 220V–230V |
| ATSC-50-FM | 50 L | 18″ × 18″ × 10″ | 750 W | 33 kHz | 5°C–25°C | 26″ × 26″ × 36″ | 220V–230V |
- Note: TT = Table Top | FM = Floor Mounted Custom volumes and frequencies available on request.
Key Features
Integrated Chiller System (5°C–25°C)
Maintains controlled cooling during sonication cycles to prevent thermal degradation of sensitive samples.
High-Efficiency Ultrasonics
33 kHz frequency with PSP (Pulse Sweep Power) technology ensures even distribution of ultrasonic energy for consistent results.
Auto Degassing Mode
Pre-programmed 5-minute ON/OFF cycle optimizes sonication by eliminating dissolved gases from the medium.
Advanced Generator Technology
Built with MOSFET/IGBT-based SMPS modules to ensure a reliable power supply and safe long-term operation.
SS304 Construction
Fabricated with 16 SWG stainless steel for chemical resistance and structural durability; includes SS lid, tray, and basket.
Digital Microcontroller Timer
Timer ranges from 1 to 99 minutes with intuitive countdown control.
User-Friendly Operation
Features a front-access drain valve, LED display, and accessible controls for ease of use.
Noise Reduction
Soundproof casing and design reduce operational noise, enhancing user comfort in lab environments.
Applications
Analytical Labs
Sample cleaning, preparation, and degassing
Pharmaceutical & Biotech
Cleaning of pipettes, flasks, vials, and glassware
Medical & Dental
Non-invasive cleaning of surgical tools and prosthetic components
Semiconductor Industry
Particle-free cleaning of wafers, optical lenses, and microelectronics
Research & Development
Sonochemical synthesis, nanoparticle dispersion, and emulsification
Additional Technical Highlights
Tank Material
SS304 (16 SWG) for long-term chemical resistance and structural stability
Degassing Cycle
Preset 5-minute auto-degassing function (5 sec ON / 5 sec OFF)
Accessories Included
Stainless steel basket, lid, tray, drain valve, user manual
Transducer Bonding
Weld-bonded bottom-mount PZT transducers for uniform cavitation
Temperature Management
Ensures safe sample temperatures during extended operations
Cooling System
Built-in closed-loop chiller with efficient heat dissipation
Why Choose Athena’s Ultrasonic Bath with Inbuilt Chiller?
Trusted Performance, Certified Assurance
The Ultrasonic Sonicator with Chiller is built to deliver consistent results across sensitive cleaning and sonication tasks. Backed by CE, FDA, ISO 9001, and GMP certifications, it meets global standards for quality, safety, and performance—making it a dependable choice for professional laboratory environments.
