Manual Hydraulic Press
Compact, Reliable Pellet Press for IR/FTIR/XRF Solid Sample Preparation
Athena Instruments introduces the Manual Hydraulic Press, a compact and precision-built laboratory press specifically designed for the manual compaction of powdered samples into solid pellets for IR, FTIR, and XRF spectroscopy. Engineered for simplicity, durability, and accuracy, this press offers reliable performance for R&D, academic, and industrial laboratories requiring cost-effective solid sample preparation.
Available in 15 Ton, 25 Ton, and 40 Ton variants, Athena’s manual presses are built for long-term operation and tested under stringent quality parameters to ensure consistent pressure delivery. Each model is certified to meet industry safety and quality standards, including CE, ISO 9001:2015, and FDA.
Key Features :
- Robust Construction: Built with heavy-duty metal housing and hydraulic components for lasting performance under regular laboratory use.
- Manual Operation: Designed with a precision hydraulic lever system for pressure application, giving full control to the user during compaction.
- Stable Pressure Delivery: Engineered to hold pressure consistently (≤1 MPa / 5 min), ensuring uniform pellet formation without deformation.
- Integrated Safety Features: Includes pressure gauge, safety valve, and solid mechanical frame to protect both user and sample.
- Compact Design: Fits easily into laboratory workspaces, requiring no external power supply or compressor—fully self-contained and portable.
Applications
IR/FTIR/XRF Solid Sample Preparation
Forms clean, dense 13 mm (or custom size) pellets for spectroscopy analysis.
Educational & Research Labs
Ideal for universities and research institutions conducting sample studies and small-batch analysis.
Pharmaceutical & Material Testing
Used for pressing powdered formulations and raw materials in analytical applications.
Quality Control & Testing Labs
Reliable tool for routine sample preparation where consistent pressure and control are essential.
Product Models & Specifications
|
Model Name |
Pressure Range |
Piston Diameter |
Single Stroke |
Table Diameter |
Workspace (mm) |
Weight |
|---|---|---|---|---|---|---|
|
AT MHP–15T |
0–15 Ton |
56 mm |
25 mm |
150 × 150 mm |
130 × 130 × 140 |
40 kg |
|
AT MHP–25T |
0–25 Ton |
63 mm |
50 mm |
185 × 185 mm |
160 × 160 × 170 |
60 kg |
| AT MHP–40T |
0–40 Ton |
85 mm |
50 mm |
260 × 260 mm |
240 × 240 × 220 |
90 kg |
- Operation:Manual
- Pressure Stability: ≤1 MPa / 5 min
- Power Requirement: Not required (fully mechanical)
- Die Compatibility:
|
Model Name |
Die Set Compatibile |
|---|---|
|
AT MHP–15T |
2 - 15 mm |
|
AT MHP–25T |
15 – 50 mm |
|
AT MHP–40T |
40 – 100 mm |
Additional Technical Highlights
Lever-Based Operation:
Smooth manual pressure application via precision hydraulic system
Maintenance-Friendly:
Simple construction with minimal service needs
Noise-Free Design:
Operates silently without motors or compressors
Protective Accessories:
Delivered with teakwood-boxed die options and safety documentation
Custom Die Support:
Compatible with Athena’s range of standard and diamond-polished dies
Why Choose Athena’s Orbital Shaker?
Trusted Performance, Certified Quality
Athena’s Manual Hydraulic Presses are built with precision, care, and compliance in mind. Designed for labs that prioritize control, durability, and affordability, each press is manufactured under strict in-house standards, ensuring reliable performance in spectroscopy sample preparation. With its compact design and proven functionality, the press is an essential tool in any modern analytical laboratory.
