Nitrogen Evaporator – Standard Series
Tabletop Solvent Evaporation System
Athena Instruments presents the Nitrogen Evaporator – Standard Series, a precision-engineered tabletop system designed for rapid, unattended, and highly controlled solvent evaporation and sample concentration. Built to meet the exacting demands of analytical, pharmaceutical, environmental, forensic, and industrial laboratories, these evaporators deliver consistent results across high-throughput workflows while ensuring operator safety and ease of use.
Available in multiple capacities supporting up to 150 samples simultaneously, each unit is manufactured from premium-grade stainless steel with advanced microprocessor controls and integrated safety features. Certified to meet CE, ISO 9001:2015, and EI standards, the Standard Series offers laboratories a robust, reliable, and cost-effective solution for solvent evaporation.
Key Features :
- Microprocessor-Controlled Operation: Accurately regulates time, temperature, and nitrogen flow for reproducible results with minimal operator intervention.
- High Sample Throughput: Processes 8 to 150 samples in parallel, optimizing laboratory efficiency for routine and high-volume applications.
- Durable Construction: Fabricated from SS316 stainless steel with a Teflon-coated water bath for exceptional corrosion resistance and longevity.
- Integrated Exhaust System: Built-in ventilation ensures safe removal of solvent vapors, maintaining a secure laboratory environment.
- User-Friendly Interface: LCD/LED display with programmable timer functions simplifies operation and reduces training time.
- Safety-Focused Design: Equipped with thermal cut-off protection, audible and visual alarms, and secure nitrogen flow control to safeguard users and samples.
- Certified Quality: CE certified, ISO 9001:2015 compliant, and EI approved, reflecting strict adherence to international standards.
Applications
Solvent
Extraction
Ideal for preparation of food, water, soil, and environmental samples.
Analytical Sample Preparation
Supports concentration workflows for LC/MS, HPLC, and other analytical methods.
Pharmaceutical & Forensic Testing
Designed for residue analysis, drug testing, and toxin detection in regulated labs.
Genomic & Proteomic Research
Concentrates samples for advanced molecular biology workflows.
Remote and Industrial Labs
Reliable solution for high-volume processing in remote or demanding environments.
Product Models & Specifications
|
Model Name |
Sample Capacity |
Water Bath Capacity | Display Type |
Nitrogen Valves |
LCD Timer Range |
LED Timer Range |
Dimensions (cm) |
Weight |
|---|---|---|---|---|---|---|---|---|
| AT-EV-08 | 8 | 6.5 Liters | LCD/LED | 2 | 1 min to 99 min | 15 sec to 10 hrs | 55 x 47 x 30 | 15 kg |
| AT-EV-24 | 24 | 6.5 Liters |
LCD/LED |
3 | 1 min to 99 min | 15 sec to 10 hrs | 55 x 47 x 30 | 20 kg |
| AT-EV-50 | 50 | 6.5 Liters | LCD/LED | 5 | 1 min to 99 min | 15 sec to 10 hrs | 55 x 47 x 30 | 20 kg |
|
AT-EV-100 |
100 | 7.5 Liters | LCD/LED | 5 | 1 min to 99 min | 15 sec to 10 hrs | 60 x 45 x 40 | 30 kg |
| AT-EV-144 | 144 | 8.5 Liters | LCD/LED | 6 | 1 min to 99 min | 15 sec to 10 hrs | 50 x 35 x 40 | 20 kg |
| AT-EV-150 | 150 | 8.5 Liters | LCD/LED | 6 | 1 min to 99 min | 15 sec to 10 hrs | 50 x 35 x 40 |
20 kg |
Additional Technical Highlights
Gas Regulator Range:
0–100 PSI for precise nitrogen flow control
Power Supply:
230 V AC / 3A / 50 Hz
Error Indicators:
LED with audible buzzer for quick fault identification
Tube Compatibility:
12–20 mm OD, up to 150 mm length
Solvent Recovery:
Enabled by default with integrated design
Working Volume:
4–30 ml
Why Choose Athena Instruments Nitrogen Evaporators?
Trusted Performance, Certified Quality
Athena’s Standard Series Nitrogen Evaporators are CE certified, ISO 9001:2015 compliant, and EI approved. Every unit is produced under rigorous in-house protocols to ensure safety, reliability, and consistent performance in demanding laboratory environments.
