Dry Box with PID Controller
Precision-Controlled Storage for Moisture-Sensitive Laboratory Accessories
Athena Instruments presents the Dry Box with PID Controller, a reliable and smart humidity-control solution engineered for the safe storage of highly moisture-sensitive accessories such as FTIR and XRF components. Built with precision and designed for uninterrupted operation, this unit maintains an optimal dry environment to protect hygroscopic materials from degradation and moisture contamination.
The system is integrated with a user-friendly PID Controller that allows accurate temperature regulation via a membrane keypad. The dual digital display clearly indicates the current (PV) and set (SV) temperatures, providing full transparency and ease of monitoring. Factory preset at 40°C, the Dry Box is capable of reaching up to 80°C, offering flexibility and stability in dry storage conditions.
Key Features :
- Advanced PID Temperature Control: Maintains consistent temperature from ambient +5°C up to 80°C with high accuracy.
- Dual Display Interface: Simultaneously displays Process Value (PV) and Set Value (SV) for real-time monitoring.
- Membrane Keypad: Intuitive controls for setting temperature with secure input via arrow keys and confirmation through Enter.
- Continuous Operation Design: Ideal for 24/7, 365-day use to ensure uninterrupted dry storage.
- Robust Construction: Durable enclosure with secure sealing to maintain internal dryness and protect sensitive component.
Applications
FTIR/XRF Accessory Storage
Designed for safe, long-term storage of optical and analytical accessories vulnerable to moisture.
Laboratories & R&D Centers
Ideal for storing hygroscopic samples, electronics, powders, and calibration tools.
Pharmaceutical & Chemical Labs
Maintains integrity of reagents and components requiring moisture-free environments.
Electronics
Industry
Prevents oxidation and moisture damage in delicate components and sensors.
Technical Specifications
|
Parameter |
Specification |
|---|---|
| Input Voltage | 230 V AC, 50 Hz |
| Temperature Range | Ambient +5°C to 100°C |
| Display Type | Dual digital display (PV/SV) |
| Control Type | PID Controller with membrane keypad |
| Fuse Rating | 1.5 Amp slow blow |
| Dimensions (L x W x H) | 407 mm x 229 mm x 368 mm |
| Construction | Rugged insulated cabinet with top lid |
|
Safety Feature |
Proper earthing and sealed operation |
Additional Technical Highlights
Temperature Stability
Uniform heating inside the chamber ensures consistent dry conditions throughout.
Safe Operation
Includes essential safety protocols such as grounding, sealed lid, and spill-prevention guidelines.
Plug-and-Play Installation
Easy to set up and operate with minimal training required.
No Maintenance Design
Minimal moving parts; designed for long-term reliability without regular servicing.
Why Choose Athena’s Dry Box with PID Controller?
Trusted Performance, Certified Reliability
Athena’s Dry Box with PID Controller is built for professionals seeking uncompromising performance and long-term protection for their lab essentials. Supported by Athena’s legacy of innovation and service, it offers peace of mind in every lab setting.
