Ultrasonic Probe Sonicator – Small Series
Athena Instruments presents the Ultrasonic Probe Sonicator – Small Series, engineered for high-efficiency liquid processing through advanced cavitation technology. Designed to meet the evolving needs of biotech, nanotech, chemical, pharmaceutical, and academic laboratories, this compact ultrasonic homogenizer ensures uniform dispersion, emulsification, cell disruption, and extraction with unmatched precision and control.
Ideal for laboratories with limited bench space, the Small Series models deliver powerful performance with intuitive controls, making them a reliable choice for research and routine applications alike.
Key Features :
- Digital Touchscreen Interface: 3.5-inch touchscreen with real-time monitoring of power, temperature, and time for complete process control.
- Intelligent Frequency Tracking: Automatic tuning maintains optimal ultrasonic performance without manual calibration.
- Pulse Mode Functionality: Programmable ON/OFF cycles (1–99 sec) reduce heat buildup, preserving sample integrity.
- Premium Transducer Technology: German ceramic piezoelectric elements ensure efficient ultrasonic energy transfer and operational longevity.
- Durable Titanium Probe: Made from TC4-grade titanium alloy, offering superior corrosion resistance and durability in high-load applications.
- Compact and Ergonomic Build: Lab-friendly footprint with quiet operation and corrosion-resistant construction, ideal for confined environments.
Applications
Cell Disruption & Lysis
Effective breakdown of bacterial, yeast, mammalian, and viral cells for molecular biology workflows.
Nanoparticle Dispersion
Uniform deagglomeration and stabilization of nanoparticles in various solvents.
Emulsification & Homogenization
Stable emulsion formation for pharmaceutical, cosmetic, and food industries.
Sonochemical Reactions
Enhance reaction rates in chemical synthesis and organic extraction.
Environmental Analysis
Sample pre-treatment for TOC, metal ions, and organic pollutant detection.
Botanical & Solid-Liquid Extraction
Efficient extraction of plant-based bio actives for nutraceutical and herbal research.
Product Models & Specifications
| Model Name |
Operating Mode |
Ultrasonic Power (W) |
Frequency (kHz) |
Amplitude/ Duty Ratio |
Capacity (ml) |
Horn Size (mm) |
Dimensions |
Weight |
|---|---|---|---|---|---|---|---|---|
|
ATP-150S |
Auto/Manual |
5–150 |
20–25 |
1–99 |
0.1 – 5 |
Ø2 | Compact | 4.2 kg |
| ATP-250S |
Auto/Manual |
5–250 |
20–25 |
1–99 |
0.1 – 10 | Ø3 |
Compact |
4.2 kg |
| ATP-400S | Auto/Manual | 5–400 | 20–25 | 1–100 | 10–100 | Ø6 |
Compact |
4.5 kg |
Note: Optional Horn sizes, cooling jackets, and additional accessories available on request.
- Power Supply: 220V / 50Hz (110V on request)
- Timer Control: 1 sec to 99 hours 99 mins 99 secs
- Optional Horn Sizes: Ø2 mm, Ø3 mm, Ø6 mm
- Working Volume: 0.1 ml – 100 ml
- Probe Material: TC4 Titanium Alloy
- Transducer Origin: German Piezo Ceramic
Other Technical Highlights
Automatic frequency adjustment
Error indicator with LED & buzzer
Stainless steel enclosure with sound insulation
Amplitude adjustable in 1% increments
Over-temperature and overload protection
Why Choose Athena Instruments' Ultrasonic Probe Sonicator – Small Series?
Trusted Performance, Certified Quality
The Ultrasonic Probe Sonicator – Small Series is CE certified, ISO 9001:2015 compliant, and manufactured to the highest international standards, ensuring performance, safety, and regulatory compliance.
