Products
Ultrasonic Cleaner – Prime Series
Digital Fabricated Ultrasonic Cleaning System for Industrial, Laboratory, and Medical Applications
Athena Instruments presents the Ultrasonic Cleaner – Prime Series, a high-capacity fabricated ultrasonic cleaning system engineered for heavy-duty applications across pharmaceuticals, research laboratories, hospitals, automotive workshops, and industrial production. Built from SS304-grade stainless steel, the Prime Series ensures structural strength, corrosion resistance, and long-lasting performance in demanding environments.
With larger tank volumes and higher ultrasonic power ratings than the Eco Series, the Prime Series is ideally suited for intensive cleaning of industrial-scale components, multipurpose glassware, precision parts, and custom batch applications.
Key Features :
- Fabricated Stainless Steel Construction: Durable SS304 fabrication provides superior rigidity, mechanical strength, and chemical resistance.
- Industrial-Grade Ultrasonic Performance: Fitted with imported PZT-type transducers bonded using weld-bond technique for powerful and uniform cavitation.
- High Power Output: Ultrasonic power ranges from 150W to 500W, supporting the removal of heavy oils, carbon residues, and fine particulates.
- Advanced Heating System: Integrated 500W heater with adjustable temperature range up to 60°C for enhanced cleaning efficiency.
- Digital Timer & Control: Programmable digital timer (1–99 minutes) for precise cleaning cycle management.
- Degas Mode: On/Off degas functionality removes trapped air bubbles, optimizing ultrasonic energy transfer.
Applications
Pharmaceutical & Hospital Use
Cleaning of surgical instruments, tablet tooling, stainless steel utensils, and lab apparatus.
Automotive & Mechanical Workshops
Degreasing and cleaning of injectors, engine parts, nozzles, and mechanical assemblies.
Laboratories & R&D Facilities
Effective cleaning of beakers, flasks, stirrers, and precision instruments.
Electronics & PCB Cleaning
Suitable for circuit boards, sensors, SMD assemblies, and delicate components.
Industrial Production
Ideal for jigs, dies, machine parts, and high-volume multi-part cleaning operations.
Product Models & Specifications
|
Model Name |
Tank Capacity | Tank Size (inches) |
Ultrasonic Power |
Heater Power |
|---|---|---|---|---|
|
ATS - 6.5 - LED |
6.5 L |
12 x 6 x 6 |
150 W |
500 W |
|
ATS - 10 - LED |
10 L |
12 x 9 x 6 |
250 W |
500 W |
|
ATS - 14 - LED |
14 L |
21 x 7 x 6 |
300 W |
500 W |
|
ATS - 20 - LED |
20 L |
14 x 12 x 8 |
400 W |
500 W |
| ATS – 20L – LED | 20 L | 24 x 9 x 6 |
400 W |
500 W |
|
ATS - 25 - LED |
25 L |
16 x 16 x 6 |
450 W |
500 W |
|
ATS - 30 - LED |
30 L |
15 x 15 x 8 |
500 W |
500 W |
|
ATS - 50 - LED |
50 L |
22 x 12 x 12 |
500 W |
500 W |
Additional Technical Highlights
Material of Construction:
Fabricated SS304 stainless steel
Transducer Type:
Imported PZT, weld-bonded
Ultrasonic Frequency:
33 kHz
Ultrasonic Generator:
Advanced MOSFET/IGBT-based SMPS for consistent power delivery
Timer Range:
1–99 minutes
Temperature Range:
Ambient to 60°C
Power Input:
230 VAC
Degas Mode:
Available (On/Off)
Accessories:
Supplied with stainless steel basket, lid, drain valve (from ATS-20 onwards), power cord, and user-friendly operation manual
Why Choose Athena’s Ultrasonic Cleaner – Prime Series?
Certified Quality, Trusted Performance
The Ultrasonic Cleaners – Prime Series are built under ISO 9001:2015-certified quality systems, comply with international safety standards, and are trusted by leading pharmaceutical, industrial, and research institutions for reliable ultrasonic cleaning performance.
