Multi Tube Vortex Shaker
High-Throughput Mixing Platform for Sample Agitation and Homogenization
Athena Instruments Pvt Ltd introduces the Multi-Tube Vortexer, a robust, high-performance laboratory mixer designed for efficient and simultaneous vortexing of multiple samples. Built to accommodate a wide range of tube formats, this vortexer is engineered for precision mixing in applications such as chemical solubilization, cell lysis, sample homogenization, and suspension agitation.
With the ability to process up to 50 tubes at once, the Multi-Tube Vortexer is ideal for laboratories that demand consistency, speed, and high-throughput performance across various testing and research environments.
Key Features :
- High-Capacity Design : Processes up to 50 samples in one run, optimizing time and effort for high-volume workflows.
- Digital Control System : Microprocessor-based control with an intuitive LED display for precise speed (500–2500 rpm) and time (1 sec – 9999 min) adjustments.
- Pulse & Continuous Operation : Built-in pulse mixing mode and programmable short-mix functionality ensure flexibility for complex protocols.
- Stable & Silent Operation : Advanced motor design ensures smooth, low-vibration performance, suitable for sensitive lab environments.
- Large Orbital Vortexing Motion : 4 mm orbit diameter enables effective vortexing and uniform agitation of liquid and semi-solid samples.
- Exchangeable Tube Racks : Compatible with multiple foam tube racks for 10 mm, 15 ml, 50 ml, and other standard formats.
Applications
Molecular Biology & Genomics
Cell lysis, DNA/RNA extraction, and buffer mixing
Pharmaceutical
R&D
Sample homogenization and mixing during drug development
Chemical
Analysis
Rapid dissolution and uniform suspension mixing
Food & Beverage Testing
Sample preparation for contaminants and quality analysis
Clinical & Diagnostic Labs
Blood, plasma, and reagent agitation for consistent test results
Product Models & Specifications
|
Model Name |
Speed Range |
Amplitude |
Timing Range |
Max Load |
Power |
Dimensions (mm) |
Weight |
|---|---|---|---|---|---|---|---|
| ATMT-2500 | 500–2500 rpm | 4 mm | 1 sec – 9999 min | 5 kg |
60 W |
385 × 225 × 440 | 15 Kg |
- Power Supply: AC 100–230V, 50/60 Hz
- Speed Accuracy: ±10 rpm
- Pulse Interval Range: 1–10 sec
- Pulse Running Time: 1 sec – 99 min 59 sec
- Operating Temperature: 4°C to 45°C
- Relative Humidity: ≤ 70%
Foam Rack Compatibility
|
Rack Type |
Tube Diameter |
Tube Capacity |
Rack Size (mm) |
|---|---|---|---|
|
AMT-A |
10 mm |
50 |
245 × 132 × 45 |
|
AMT-B |
12 mm | 50 | 245 × 132 × 45 |
| AMT-C | 13 mm | 50 | 245 × 132 × 45 |
| AMT-D | 15 ml / 16 mm | 50 | 245 × 132 × 45 |
| AMT-E | 25 mm | 15 | 245 × 132 × 45 |
| AMT-F |
50 ml |
15 | 245 × 132 × 45 |
| AMT-H | Tray Pad | — | 305 × 178.5 × 25 |
Note: One tube frame of your choice (5 ml / 15 ml / 50 ml) is included. Additional frames are available upon request at extra cost.
Additional Technical Highlights
Material of Construction:
Industrial-grade housing with non-corrosive internal mechanisms
Sealing & Safety:
Designed for long operational hours with internal safeguards
Control Panel:
Ergonomic, tactile keypad for accurate parameter control
Sampling Modes:
Compatible with touch (short mix) and continuous operation
System Integration:
USB interface for software-based updates or custom programming
Why Choose Athena Instruments Multi-Tube Vortexer?
Trusted Performance, Certified Quality
Athena’s Multi-Tube Vortexer is built under stringent in-house quality control standards and adheres to global compliance certifications—offering trusted performance, safety, and innovation for scientific laboratories worldwide.
